M Drone | Medium Drone 20KG

We specialize in drone manufacturing, if you are interested please contact us, we will be grateful.



M5 is a medium and large unmanned bomber, with the characteristics of large bomb load and flight time. With a maximum load of 20kg and a flight time of up to 180 minutes, it adopts a double-tail brace layout, and the cruising flight uses 2 independent power systems and dual power backup.



Dimension

Body length：2580 mm

Wingspan：4800 mm

Weight

Aircraft Weight：20 kg

Max. Payload：20 kg

Max. Takeoff Weight：55 kg

Performance

Max. Flight Time：180 min

Cruising Speed：26 m/s

Max. Horizontal Speed：40 m/s

Max. Ascent Speed：3 m/s

Max. Descent Speed：2.5 m/s

Max. Flight Altitude：4500 m

Comm. & Nav

Transmission Range：80 km

GNSS：GPS+GLONASS+BeiDou+Galileo

Environment

Max. Wind Resistance：Level 7

IP Protection Rating：IP54

Operating Temperature：-20~60℃

Packaging

Package Dimensions：Fuselage Box: 1810*980*720 mm

Tail Box: 1800*460*1110 mm

Package Weight：Fuselage Box: 92 kg

Tail Box: 39 kg

Features

• Long voyage
• Quick disassembly
• Positioning targets in multiple ways
• VTOL
• Strong stealth
• Strong wind resistance
• Precise blow
• Super-strong anti-interference
• Intelligent and standardized design
